STG4840 High Precision Pressure Sensor
The STG4840 high-precision pressure sensor is designed for demanding industrial measurement applications. It features a highly stable sensing element and an all-stainless-steel housing. Its internal signal conditioning circuit is optimized with laser trimming and wide-temperature compensation technology, ensuring high accuracy and long-term stability across the full operating range. With an accuracy of up to ±0.05% F.S., the STG4840 delivers excellent reliability and anti-interference performance, making it ideal for aerospace, semiconductor equipment, material testing, and precision metrology applications. The sensor supports both gauge and absolute pressure measurements, with standard industrial output signals including 4-20mA, 0-5V, and 0-10V for seamless integration into automation systems. Pressure ranges span from 16 bar to 1000 bar, with multiple mechanical interfaces such as G1/4, G1/2, and M20×1.5. It offers optional IP65/IP67 protection, along with reverse polarity, overvoltage, and overcurrent protection. Fully compliant with EMI standards, it ensures stable operation in complex electromagnetic environments. With long-term stability of ≤±0.1% F.S/year, fast response time (<1 ms), and a wide operating temperature range of -40 to 125°C, the STG4840 is an ideal solution for high-precision industrial pressure measurement systems.
