Q1: What media can the STG26 Differential Pressure Transmitter measure?
The STG26 Differential Pressure Transmitter is designed for gas media measurement and is widely used in medical devices, wind tunnel testing, furnace monitoring, and leak detection applications.
Q2: What output signals does the STG26 Differential Pressure Transmitter support?
This transmitter offers multiple output options, including 4–20mA, 0–5V, 0–10V, Modbus-485 RTU, and CANopen, compatible with various control systems.
Q3: What is the measurement accuracy of the STG26 Differential Pressure Transmitter?
The STG26 Differential Pressure Transmitter can achieve up to ±0.07% F.S accuracy, ensuring highly precise differential pressure measurement.
Q4: Can the STG26 Differential Pressure Transmitter operate in harsh environments?
Yes, it features strong vibration, shock, and electromagnetic interference resistance, along with software temperature compensation, making it suitable for demanding industrial and laboratory environments.
Q5: What is the measurement range of the STG26 Differential Pressure Transmitter?
The STG26 Differential Pressure Transmitter covers ranges from 0~±100Pa up to 0~100000Pa, suitable for both micro and high differential pressure measurements.
Q6: Which industries can use the STG26 Differential Pressure Transmitter?
It is widely used in medical devices, wind tunnel testing, furnace monitoring, leak detection, high-precision industrial applications, and component integrity testing.
Q7: What is the protection rating and housing material of the STG26 Differential Pressure Transmitter?
The STG26 Differential Pressure Transmitter features an aluminum alloy housing with IP67 protection, suitable for humid and dusty industrial environments.
Q8: What is the temperature range for the STG26 Differential Pressure Transmitter?
The operating temperature range is -35~125℃, with a temperature compensation range of -35~85℃, and the storage temperature also ranges from -35~125℃.
