Q1: What industrial applications is the STG07 Grouting Flat Diaphragm Pressure Transmitter suitable for?
The STG07 Grouting Flat Diaphragm Pressure Transmitter is widely used for pressure measurement in engineering equipment, metallurgical automation, and other industrial processes. It is especially suitable for tunnel boring machines, powder handling equipment, grinding machines, slurry equipment, and fluid systems.
Q2: What are the main features of the STG07 Grouting Flat Diaphragm Pressure Transmitter?
This transmitter uses a stainless steel isolation diaphragm with a silicon pressure sensing element, providing high sensitivity. Its flat diaphragm design ensures accurate pressure measurement. It also offers reverse polarity protection, transient overcurrent and overvoltage protection, and multiple output options, including 4~20mA, 0-5V, 1-5V, 0-10V, and Modbus485-RTU, while meeting EMC protection standards for reliable performance.
Q3: What are the electrical and physical specifications of the STG07 Grouting Flat Diaphragm Pressure Transmitter?
The pressure range is from 0~6 to 200Bar, available in gauge or absolute pressure. Operating voltage options are 12VDC or 24VDC. Accuracy reaches ±0.2%F.S with long-term stability ≤±0.1%F.S/year. The transmitter features a 304 stainless steel housing, R1 or G1 mechanical connections, vibration and shock resistance, and protection ratings up to IP68.
Q4: What are the temperature and medium compatibility of the STG07 Grouting Flat Diaphragm Pressure Transmitter?
Temperature compensation range is -25~85°C, with operating and storage temperatures of -40~125°C. It is compatible with gases and liquids that do not corrode stainless steel 304/316L, suitable for extreme industrial environments.
Q5: How reliable is the STG07 Grouting Flat Diaphragm Pressure Transmitter?
The STG07 Grouting Flat Diaphragm Pressure Transmitter undergoes rigorous component, semi-finished, and finished product testing and aging screening. Laser trimming ensures zero and temperature compensation across a wide temperature range, guaranteeing long-term stability and high reliability in demanding industrial conditions.
